Offer 379294
OMET X-FLEX X6 430 from 2013
Label Flexo
Offer Details
| Offer Number: | 379294 |
|---|---|
| Brand: | OMET |
| Model: | X-FLEX X6 430 |
| Manufacturer | OMET |
| Condition: | Good |
| Year: | 2013 |
| Incoterm: | EX Works |
| Cylinders Condition: | |
| Under Power: | Yes |
| Still in production: | Yes |
| Test possible: | Yes |
| Complete and in working condition: | Yes |
| Availability: | |
| Counter: | |
| Machine number: | |
| Description: | Maximum speed (dependent on printing size): 660 FPM - 200 m/minute<>Maximum web width: 430 mm (17")<>Flexo Printing repeat range: 12" - 25"<>Flexo Printing repeat range (only reel to reel): 304,8 - 635 mm<>Maximum flexo printing width: 420 mm (16" ½)<>Substrate thickness range: 12 micron - 250 gr/sqm<>Web tension: 4-30 kg<>Main PLC Schneider Electric<>Drivers and motors Emerson - Control Techniques<>Standard machine voltage 400/480 V AC three-phase<>+ 50/60 Hz. + Earth<>Regulations "CE" Mark<>1 Basic press XFlex X6 430 for the printing of filmic and pressure sensitive stock, complete of:<>- Automatic tension unwinder, for rolls up to 1000 mm (40") diameter, with integrated roll pick up from the floor,<>- Servo-driven infeed section, with automatic web tension control,<>- Servo-driven outfeed section with independent motor<>- Mounting frame for slitting systems (not included, quoted separately)<>- Pair of web break detectors<>- Single shaft rewinder, with independent motor for constant tension control, for rolls up to 1000 mm (40") diameter, including integrated roll discharge system.<>- Operator Interface, through a touch screen panel<>- Unwinder and rewinder 450 kg<>SERVODRIVEN AND GEARLESS FLEXO PRINTING UNIT<>8 SHAFTLESS and GEARLESS Direct Drive flexo printing unit, complete with sleeve system plate change over. Includes: |
Technical details
| Max. Web width: | 430 mm |
|---|---|
| Max.Print width | 420 mm (16" 4/8) |
| Max mechanical Speed | 660 FPM |
| HS Code | 84431600 |
PRICE: Upon request
