For blind, foil, and relief embossing of rigid, flexible, and<>plastic covers.<>Extra - Die plate for mounting embossing dies<>Die plate with grid-pattern holes for mounting<>embossing dies (Bolted connection)<>Mobile counting and stacking delivery unit<>(max. stack height 100 mm)<>Format range<>Opened cover: max. 450 x 390 mm<>To be provided by the customer:<>Compressed air requirement: 1 Nm³/h<>Operating pressure: 6 bar<>Counting and stacking delivery unit (right-hand exit)<>with roller conveyor discharge, incl. table<>Embossing dwell time extension unit<>(Selectable setting range: 0.5 – 10 seconds.<>Cycle speed is reduced accordingly.)<>Multiple stamping device<>Stepped feed for optimal foil utilization<>- Copilot system with touchscreen<>• Production selection<>• Operator-guided job changes<>• Product counters (job, shift, and start/stop counters)<>• Display of machine faults and material flow issues<>• Operator-guided troubleshooting<>- Cover pre-stacking belt (shingled feeding)<>- Automatic cover bending unit (DBA)<>- Cover feed swiveling by 90° (format-dependent)<>- Foil feed unit with two stepper-motor-controlled foil feed rollers<>• Adjustable foil feed speed<>- Unwind unit<>- Foil lifter<>- Motorized embossing head adjustment (max. 70 mm)<>- Split embossing table plate<>- Correction bars for register-accurate positioning<>- Temperature-controlled embossing head heating<>with timer for preheating<>- Light barriers and vacuum monitoring<>for process monitoring<>- Linear delivery belt with delivery table incl. shingle spacing adjustment<>- Automatic cover counter<>- Automatic central lubrication<>- 1 Matrix plate<>Technical specifications:<>Max. mechanical speed: embossings/min<>Max. opened case size: 660 x 405 mm<>Min. oppened case size: 55 x 100 mm<>Max. opened case size: 400 x 300 mm (flexible embossing material):<>Min. opened case size 135 x 100 mm (flexible embossing material):<>Case pre-stacking conveyor: min. 155 mm<>Pressure surface: max. 460 x 355 mm<>Pressing force: 350 KN
